Black Ink

kroger

New Member
Is there any way I can fix the black issue? I manually cleaned it and did a medium clean. I have replaced a few black printheads. (More than I would like). This printhead was replaced in the spring I think. So not that old. I can print black much better than what my test print shows. Any suggestions?


Attachments

  • image.jpg
    1.7 MB · Views: 210
  • D6AA3447-0A69-452F-B876-3665034645C6.jpeg
    1.1 MB · Views: 142
  • image.jpg
    1.4 MB · Views: 147

Solventinkjet

DIY Printer Fixing Guide
If your head is already deflecting after such a short time you might just need a new cap top. It might not be sealing well which causes the nozzles to dry out and fail to recover during cleanings. I'd probably throw a new cap in, do a head soak, and then run a strong cleaning. That should help if not fix the issue.


ikarasu

Active Member
The reason you can print black better than your test print, is your test print is only using 100% Black. When you print black via your rip, it's adding other colors...the other colors will hide the banding better. Thats why you'll see in the guitar picture, the black is fine.



I second the cap-top... Apparently roland recommends replacing them every 6 months - seems a little quick to me, but I imagine most people here never change their cap tops, so its still likely due for one?
