Crazy Yellow test print and group c not firing...help
- Thread starter jason91
- Start date
Triggerhappy
New Member
what kind of printer is it? When printing does it do the same?
Looks data related to me. Did you check all the cables? Done any work on the heads or printer lately?
Printer model & backround information would help.
Yeah, on one of my older printers, sometimes every other head won't fire on the jet-out due to a circuit board glitch, luckily all I have to do is reboot the printer.
Looks like a cable or board is messing up.
You guys were right about the yellow... The cable wasn't pushed in the head all the way.... Still I wonder what the deal is why the light magenta and light cyan won't print (group c) ... I know there is ink in the dampers and the head because I've pulled ink through them... They just won't fire
You might check the tiny fuse on the head board - Should be F3...(if it is a Roland XC540 Pro III - That was a problem on mine, plus I had shorted out the head board and had to have it sent for repair because I got cleaner on the board on the light magenta board... Then I had to get a new head for it too... Expensive mistake...
