UJV 160 Error 09 HDC POSCNT~~~PLEASE HELP!

EffectiveCause

Premium Subscriber
I have a UJV-160 that has been having problems tracking its posistion while printing(see attached pic).
attachment.php

After cleaning the dust off the linear encoder strip and out of the sensor, as we have done before to make this problem go away, we got this "ERROR 09 HDC POSCNT". The Mimaki tech support said we needed to replace the linear encoder strip. Did that and still geting the same error. Any help would be appreciated.


Attachments

  • 20150520_070500_resized.jpg
    19.2 KB · Views: 2,116

Kathi Hauser

Sign Girl
and you cleaned the sensor that reads the encoder strip?

loosing an equal distance with each pass?
Check the carriage belt and motor...
Sounds like its slipping.


J Hill Designs

New Member
and you cleaned the sensor that reads the encoder strip?

loosing an equal distance with each pass?
Check the carriage belt and motor...
Sounds like its slipping.

the stepping is from encoder issues, which he/she knew.

after cleaning the strip and sensor, an error popped up


Kathi Hauser

Sign Girl
I'm sorry,
I have to say the obvious...it was mentioned the encoder was replaced and the cable for the sensor checked, but perhaps they overlooked cleaning the actual sensor.
But it sounds more like the latter I mentioned.


J Hill Designs

New Member
ERROR 509 HDC POSCNT
HDC position counter error
1. Execute and confirm [#TEST]->[SENSOR TEST] -
>[Y-ORG].(Confirm that the ON/OFF display is switched by moving the carriage left and right.)
2.[Execute [#TEST]->[CHECK ENCODER].
3.Check the assembly of Y-scale, and confirm that there is neither dirt nor scratch.
4.Check in manual if the Head Assy. (carriage) moves left and right smoothly.
5.Check the connector connection of Y-origin Sensor and Linear Encoder.
6.Replace the Y-origin Sensor or Linear Encoder with a new one.
7.Check the assembly and connector connection of Y- axis Motor.
8.Replace the Y-axis Motor with a new one.
9.Replace the Slider PCB with a new one.
10.Replace the SL-Relay PCB with a new one.
11.Replace the Main PCB with a new one.


EffectiveCause

Premium Subscriber
ERROR 509 HDC POSCNT
HDC position counter error
1. Execute and confirm [#TEST]->[SENSOR TEST] -
>[Y-ORG].(Confirm that the ON/OFF display is switched by moving the carriage left and right.)
2.[Execute [#TEST]->[CHECK ENCODER].
3.Check the assembly of Y-scale, and confirm that there is neither dirt nor scratch.
4.Check in manual if the Head Assy. (carriage) moves left and right smoothly.
5.Check the connector connection of Y-origin Sensor and Linear Encoder.
6.Replace the Y-origin Sensor or Linear Encoder with a new one.
7.Check the assembly and connector connection of Y- axis Motor.
8.Replace the Y-axis Motor with a new one.
9.Replace the Slider PCB with a new one.
10.Replace the SL-Relay PCB with a new one.
11.Replace the Main PCB with a new one.

So if the display isnt switching between on and off when you move the head what does that mean?


EffectiveCause

Premium Subscriber
ERROR 509 HDC POSCNT
HDC position counter error
1. Execute and confirm [#TEST]->[SENSOR TEST] -
>[Y-ORG].(Confirm that the ON/OFF display is switched by moving the carriage left and right.)
2.[Execute [#TEST]->[CHECK ENCODER].
3.Check the assembly of Y-scale, and confirm that there is neither dirt nor scratch.
4.Check in manual if the Head Assy. (carriage) moves left and right smoothly.
5.Check the connector connection of Y-origin Sensor and Linear Encoder.
6.Replace the Y-origin Sensor or Linear Encoder with a new one.
7.Check the assembly and connector connection of Y- axis Motor.
8.Replace the Y-axis Motor with a new one.
9.Replace the Slider PCB with a new one.
10.Replace the SL-Relay PCB with a new one.
11.Replace the Main PCB with a new one.

One more question. So when performing the check encoder, the m number changes but the e number does not. Does this mean it could be the encoder is bad?


EffectiveCause

Premium Subscriber
ok replaced the encoder and its working now. I can diffinitly tell the difference of how much sharper the image looks now with the new parts. Thanks for the help!
